APW12_12V-15V EMC （f calibration Version）

$172.00

For S19,S19 Pro,S19j Pro,S19 XP,S19j Pro+,S19k Pro

Note:

This power supply is version f

You can check the exact version at the product tag which is on the side of the power supply and find the newest firmware accordingly from official website: Firmware Download

There are many versions of this power supply, it is recommended to consult customer service before purchasing>>Contact now

Product Glance
Out1
DC Voltage 12V-15V
Rated Current(220V input) 208A (when 15V can upto 233A~240A)
Ripple & Noise <1%
Line Regulation <1%
Load Regulation <1%
Setup Time <2S
Short Circuit Protection >10mS
Detailed Characteristics
Out2
DC Voltage 12.3V
Rated Current(220 V input) 15A
Ripple & Noise <1%
Voltage Accuracy 12.2V—12.4V
Line Regulation <1%
Load Regulation <1%
Setup Time <2S
Short Circuit Protection >10mS
Input
Voltage Range 200-240V AC
Frequency Range 47-63Hz
Power Factor >0.99(full load)
Leakage Current <1.5mA（220V 50Hz）
Protection
Low-voltage Input 80-89V AC
Output Short Circuit Yes
Overheat Protection Yes
Over-current Output 291A-350A （protection value varies under different voltage）
Environment
Operating Temperature -20-45℃
Operating Humidity 20%-90%RH（non–condensing）
Altitude < 2000m
Structure
Dimensions 254.6mm*251.6mm*63mm
Net Weight 3.6kg
Cooling System Forced‐air cooling
Noise 45dBA
